REVIEWED STOCK BUILD

Stock Specifications

These assignments come from the selected reviewed bike configuration. Unavailable details remain explicit.

Brakes

Front Brake: Stock specification unavailable
Rear Brake: Stock specification unavailable
Front Rotor: Shimano SM-RT66 Disc Brake Rotor 160 mm · 6-bolt
Rear Rotor: Shimano SM-RT66 Disc Brake Rotor 160 mm · 6-bolt

Cockpit

Saddle: Trek Verse Short Comp Bike Saddle 250mm x 145mm
Handlebar: Bontrager Domane AL 5 Installed Comp Road Handlebar 360/400 mm
Stem: Bontrager Domane AL 4 Installed Elite Stem 70 mm / 7 degrees / factory 564679
Seatpost: Bontrager Domane AL 5 Installed Comp Seatpost 27.2 mm / 250 mm / 8 mm offset

REVIEWED MEASUREMENTS

Technical Data

Published fit, weight, and geometry for the selected configuration. Missing measurements remain explicit.

Fit & Weight

Recommended Rider Height: 4′ 11″–5′ 0″ (150–153 cm)
Advertised Assembled Weight: 22.3 lb (10.1 kg)Manufacturer assembled-bike reference weight measured in size 56; not a measurement of another size

Geometry

Exact-size manufacturer geometry. Weight is the model reference measurement in size56. Installed chain length and caliper identity are unpublished; those facts remain Unknown.

Stack	510 mm
Reach	360 mm
Standover	657 mm
Seat Tube	390 mm
Effective Top Tube	507 mm
Head Tube	95 mm
Chainstay	420 mm
Wheelbase	983 mm
Bottom Bracket Drop	80 mm
Fork Offset	53 mm
Head Angle	70.3°
Seat Angle	74.6°
