Canyon Endurace CF 7 2027 · BikePartPicker

REVIEWED STOCK BUILD

Stock Specifications

These assignments come from the selected reviewed bike configuration. Unavailable details remain explicit.

Chassis

Frameset: Canyon Endurace CF R129 Stock Frame 2027 R129 / 2XS
Fork: Canyon FK0154 CF Disc Stock Fork 12x100 / 38mm tire clearance / 1.25in upper steerer

Wheels & Tires

Front Wheel: DT Swiss Endurance LN 24mm Installed front Wheel 700c / 12x100 / 24mm depth
Rear Wheel: DT Swiss Endurance LN 24mm Installed rear Wheel 700c / 12x142 / 24mm depth
Front Tire: Continental Grand Prix Clincher Installed Tire 32-622 / exact US4627 installed option
Rear Tire: Continental Grand Prix Clincher Installed Tire 32-622 / exact US4627 installed option

Drivetrain

Crankset: Shimano 105 FC-R7100 Crankset 50-34T · 160 mm
Bottom Bracket: Shimano BB-RS500-PB Bottom Bracket Press-fit 86.5 mm
Cassette: Shimano CS-HG710-12 Cassette 12-speed 11-36T
Chain: Shimano CN-M6100 Chain 138 links · 12-speed
Front Derailleur: Shimano 105 FD-R7100 Front Derailleur Braze-on
Rear Derailleur: Shimano 105 RD-R7100 Rear Derailleur Mechanical 2x12-speed · 11-34T / 11-36T
Left Controls: Shimano 105 ST-R7120 Shift/Brake Lever Left · 2-speed front shift/brake
Right Controls: Shimano 105 ST-R7120 Shift/Brake Lever Right · 12-speed rear shift/brake

Brakes

Front Brake: Shimano Installed front Hydraulic Caliper Factory stock reference / exact caliper model unreported
Rear Brake: Shimano Installed rear Hydraulic Caliper Factory stock reference / exact caliper model unreported
Front Rotor: Shimano RT-CL300 Disc Brake Rotor 160 mm · Center Lock · dual-tool lockring
Rear Rotor: Shimano RT-CL300 Disc Brake Rotor 160 mm · Center Lock · dual-tool lockring

Cockpit

Handlebar: Canyon HB0076 AL Road Dropbar 380 mm / 31.8mm clamp
Stem: Canyon ST0035 1 1/4in AL Road & Gravel Stem 70 mm / reversible10deg
Seatpost: Grizl 6 Canyon SP0057 VCLS Stock seatpost Factory stock reference
Saddle: Grizl 6 Selle Royal SRX Stock saddle Factory stock reference

REVIEWED MEASUREMENTS

Technical Data

Published fit, weight, and geometry for the selected configuration. Missing measurements remain explicit.

Fit & Weight

Recommended Rider Height: Unavailable
Advertised Assembled Weight: 20.6 lb (9.3 kg)Measured on size M. Manufacturer published20.57lb sizeM standard specification, converted exactly to grams. Reference projection within this exact4627build; other sizes not individually weighed

Geometry

Exact2027US4627/R129 physical-size geometry. Canyon Wheel Base values1.006–1.067 are European thousands punctuation, confirmed by the detailed HTML geometry and model-linked printable HTML table. Fork offset is unpublished. Rider height ≤ 165cm is open-ended; closed-range schema intentionally left unset. No dimensions borrowed from older FK0110 or regional builds.

Stack	525 mm
Reach	382 mm
Standover	734 mm
Seat Tube	432 mm
Effective Top Tube	537 mm
Head Tube	104 mm
Chainstay	420 mm
Wheelbase	1006 mm
Bottom Bracket Drop	74 mm
Fork Offset	Unavailable
Head Angle	70.3°
Seat Angle	73.5°

Sources

www.canyon.commanufacturer
